Applicable Object: wood, stone loading and unloading operation
Product Features:
360 degree hydraulic rotation to provide more flexible grasping effect;
The balance valve is built in the cylinder, which runs smoothly, keeps clampingforce and has higher safety.
Motor bi-directional fow valve and bi-directional balance valve to avoid hydraulicimact on the motor.
| Item/Model | Weight | Max jaw opening | Oil pressure | Set up pressure | Operating flux | Cylinder Volume | Suitable excavator |
| Unit | kg | mm | kg/2cm | kg/2cm | L/min | ton | ton |
| ZL03Z | 320 | 1300 | 110-140 | 170 | 30-55 | 4.0×2 | 4-6 |
| ZL04Z | 390 | 1400 | 120-160 | 180 | 100-140 | 9.7x2 | 17-23 |
| ZL06Z | 740 | 1800 | 150-170 | 190 | 50-100 | 24.5×2 | 7-11 |
| ZL08Z | 1380 | 2300 | 160-180 | 200 | 100-140 | 9.7x2 | 17-23 |
| ZL10Z | 1850 | 2500 | 160-180 | 210 | 130-170 | 12×2 | 24-30 |
| ZL14Z | 1900 | 2500 | 180-200 | 250 | 200-250 | 12×2 | 31-40 |
| ZL20Z | 2300 | 2700 | 180-200 | 250 | 250-320 | 14×2 | 41-50 |
